Thermal Imaging Rangefinder
Hawkeep HKP-SL series is a compact thermal imaging monocular of Hawkeep brand, with a built-in laser rangefinder. It was newly developed in 2023, based on modern infrared sensors, and can provide high-quality images.
Description
HAWKEEP HKP-SL Series Thermal Imaging Camera
Product overview
1. Lens cover
2. Lens focusing ring
3. Power on / off button
4. Navigation up button
5. Menu button
6. Navigation down button
7. LED indicator (Green = power on; Red = charging)
8. Eyepiece focusing ring
9. Red laser pointer
10. Laser rangefinder
11. Data compartment
12. Hand strap
13. Objective lens
14. Eyepiece lens
15. Battery cap
Description
Hawkeep HKP-SL series is a compact thermal imaging monocular of Hawkeep brand, with a built-in laser rangefinder. It was newly developed in 2023, based on modern infrared sensors, and can provide high-quality images.
The detection distance can reach 3000 meters.
Optical zoom can see objects far away, and HKP-SL series thermal cameras also have recording and video recording functions, which can record everything you see in the instrument.
There are five display modes, white hot, sky mode, black hot, red hot, and fusion.
Features
Configuration
HKP-SL series handheld thermal imaging
Type-C cable
Instruction manual
18650 lithium battery
5V2A adapter
Hand strap
HKP-3SL series parameters
|
Brand |
HAWKEEP |
|||
|
Model |
HKP-315SL |
HKP-319SL |
HKP-325SL |
HKP-335SL |
|
Sensor |
||||
|
Type |
Uncooled |
|||
|
Resolution |
384×288 (super sensitive) |
|||
|
Frame rate |
50Hz |
|||
|
Pixel size |
12μm |
|||
|
NETD |
<30mK |
|||
|
Optical characteristics |
||||
|
Objective lens |
f19/25/35mm, F/1.0 |
|||
|
Magnification |
1.5x/2x/2.8x |
|||
|
Digital zoom |
1x/2x/4x/8x |
|||
|
Eye relief |
30mm |
|||
|
Diopter adjustment |
±5D |
|||
|
Focus scope range |
5m~∞ |
|||
|
FOV |
13.8°×10.4° / 10.5°×7.9° / 7.5°×5.7° |
|||
|
Display |
||||
|
Operating mode |
White hot, black hot, sky mode, red hot, fusion |
|||
|
Type / Resolution |
0.39-inch / OLED / 1024×768 |
|||
|
Operating characteristics |
||||
|
Power supply |
3~4.2v |
|||
|
Waterproof rating |
IP66 |
|||
|
External power supply |
5v (USB) |
|||
|
Battery |
18650 / 3500mAh |
|||
|
Operating temperature |
-20℃ ~ +50℃ |
|||
|
Dimension |
156×68×75mm |
|||
|
Weight (Without battery / mount) |
390g |
|||
|
Operating time (at temperature of 22℃) |
8h |
|||
|
Video recorder |
||||
|
Video / Photo resolution |
1024×768 |
|||
|
Video / Photo format |
.mp4 / .JPG |
|||
|
Supported memory type |
Built-in 32G memory card |
|||
|
WIFI channel |
||||
|
Frequency |
2.4GHz |
|||
|
Standard |
802.11 b/g |
|||
|
WIFI signal range |
15m |
|||
|
Rangefinder |
||||
|
Wavelength |
905nm |
|||
|
Max. measuring range |
1200m |
|||
|
Measuring accuracy |
±1m |
|||
|
Detection distance (Target size: 1.7m×0.5m) |
955m/1250m/1750m |
|||
HKP-6SL series parameters
|
Brand |
HAWKEEP |
|||
|
Model |
HKP-615SL |
HKP-619SL |
HKP-625SL |
HKP-635SL |
|
Sensor |
||||
|
Type |
Uncooled |
|||
|
Resolution |
384×288 (super sensitive) |
|||
|
Frame rate |
50Hz |
|||
|
Pixel size |
12μm |
|||
|
NETD |
<25mK |
|||
|
Optical characteristics |
||||
|
Objective lens |
f19/25/35mm, F/1.0 |
|||
|
Magnification |
0.9x/1.2x/1.7x |
|||
|
Digital zoom |
1x/2x/4x/8x |
|||
|
Eye relief |
30mm |
|||
|
Diopter adjustment |
±5D |
|||
|
Focus scope range |
5m~∞ |
|||
|
FOV |
22.9°×18.4° / 17.5°×13.1° /12.5°×9.4° |
|||
|
Display |
||||
|
Operating mode |
White hot, black hot, sky mode, red hot, fusion |
|||
|
Type / Resolution |
0.39-inch / OLED / 1024×768 |
|||
|
Operating characteristics |
||||
|
Power supply |
3~4.2v |
|||
|
Waterproof rating |
IP66 |
|||
|
External power supply |
5v (USB) |
|||
|
Battery |
18650 / 3500mAh |
|||
|
Operating temperature |
-20℃ ~ +50℃ |
|||
|
Dimension |
156×68×75mm |
|||
|
Weight (Without battery / mount) |
390g |
|||
|
Operating time (at temperature of 22℃) |
8h |
|||
|
Video recorder |
||||
|
Video / Photo resolution |
1024×768 |
|||
|
Video / Photo format |
.mp4 / .JPG |
|||
|
Supported memory type |
Built-in 32G memory card |
|||
|
WIFI channel |
||||
|
Frequency |
2.4GHz |
|||
|
Standard |
802.11 b/g |
|||
|
WIFI signal range |
15m |
|||
|
Rangefinder |
||||
|
Wavelength |
905nm |
|||
|
Max. measuring range |
1200m |
|||
|
Measuring accuracy |
±1m |
|||
|
Detection distance (Target size: 1.7m×0.5m) |
955m/1250m/1750m |
|||
Attention
Power adapter
Charging only available with the voltage equal or below 5V/2A.
Red laser pointer adjustment
Hold the MENU button to turn on/off the red laser pointer. Adjust the position of the red laser pointer by using an inner hexagon wrench.
Connect to a computer
Turn off the device and connect to the computer with a Type-C cable. Hold the power button to turn on the device. The computer will read the memory card of the device.
