Handheld Thermal Imaging Monocular

HAWKEEP HKP-SM Series Handheld Thermal Imaging Camera



1. Lens cover

2. Objective focusing ring

3. Power on / Standby button

4. Navigation up button

5. Menu button

6. Navigation down button

7. LED indicator (Green = power on; Red = charging)

8. Eyepiece focusing ring

9. Red laser pointer

10. Data compartment

11. Hand strap

12. Objective lens

13. Eyepiece lens

14. Battery cap





HKP-SM series hand-held thermal imager is an integrated thermal imager with five operation modes. It provides five modes: white hot, sky mode, black hot, red hot and fusion, which can be applied in different scenes and under different conditions. The default mode of the device is "White Hot".



This series of devices also supports CVBS video output. You can also switch the screen brightness freely, the default brightness is set to "normal", and you can also customize the target brightness and contrast.



The instrument also has audio recording function, time adjustment function, language selection function and formatting function. However, please note that the formatted data cannot be recovered. You can also set the automatic shutdown time, 3 minutes, 5 minutes, or turn off, and the instrument is set to "off" by default.



HKP-SM series equipment also has the function of "pixel repair", which can repair bad pixels, and the function of "image correction" can unify the background image.







SM series thermal imaging camera

Type-C cable

Instruction manual

18650 lithium battery

5V2A adapter

Hand strap





Brand	HAWKEEP
Model	HKP-315SM	HKP-319SM	HKP-325SM	HKP-335SM
Sensor
Type	Uncooled
Resolution	384×288 (super sensitive)
Frame rate	50Hz
Pixel size	12μm
NETD	<30mK
Optical characteristics
Objective lens	f19/25/35mm, F/1.0
Magnification	1.5x/2x/2.8x
Digital zoom	1x/2x/4x/8x
Eye relief	30mm
Diopter adjustment	±5D
Focus scope range	5m~∞
FOV	13.8°×10.4° / 10.5°×7.9° / 7.5°×5.7°
Display
Operating mode	White hot, black hot, sky mode, red hot, fusion
Type / Resolution	0.39-inch / OLED / 1024×768
Operating characteristics
Power supply	3~4.2v
Waterproof rating	IP67
External power supply	5v (USB)
Battery	18650 / 3500mAh
Operating temperature	-20℃ ~ +50℃
Dimension	156×54×75mm
Weight (Without battery / mount)	308g
Operating time (at temperature of 22℃)	8h
Video recorder
Video / Photo resolution	1024×768
Video / Photo format	.mp4 / .JPG
Supported memory type	Built-in 32G memory card
WIFI channel
Frequency	2.4GHz
Standard	802.11 b/g
Line-of-sight reception range	15m
Detection distance (Target size: 1.7m × 0.5m)	955m/1250m/1750m





Brand	HAWKEEP
Model	HKP-615SM	HKP-619SM	HKP-625SM	HKP-635SM
Sensor
Type	Uncooled
Resolution	640×512 (super sensitive)
Frame rate	50Hz
Pixel size	12μm
NETD	<25mK
Optical characteristics
Objective lens	f19/25/35mm, F/1.0
Magnification	0.9x/1.2x/1.7x
Digital zoom	1x/2x/4x/8x
Eye relief	30mm
Diopter adjustment	±5D
Focus scope range	5m~∞
FOV	22.9°×18.4° / 17.5°×13.1° / 12.5°×9.4°
Display
Operating mode	White hot, black hot, sky mode, red hot, fusion
Type / Resolution	0.39-inch / OLED / 1024×768
Operating characteristics
Power supply	3~4.2v
Waterproof rating	IP67
External power supply	5v (USB)
Battery	18650 / 3500mAh
Operating temperature	-20℃ ~ +50℃
Dimension	156×54×75mm
Weight (Without battery / mount)	308g
Operating time (at temperature of 22℃)	8h
Video recorder
Video / Photo resolution	1024×768
Video / Photo format	.mp4 / .JPG
Supported memory type	Built-in 32G memory card
WIFI channel
Frequency	2.4GHz
Standard	802.11 b/g
Line-of-sight reception range	15m
Detection distance (Target size: 1.7m × 0.5m)	955m/1250m/1750m





Power adapter

Charging only available with the voltage equal or below 5V/2A.



Red laser pointer adjustment

Hold the MENU button to turn on/off the red laser pointer. Adjust the position of the red laser pointer by using an inner hexagon wrench.



Connect to a computer

Turn off the device and connect to the computer with a Type-C cable. Hold the power button to turn on the device. The computer will read the memory card of the device.
